RAL 5014 Pigeon Blue Fine texture Powder Coating
PP1F-400162 · Standard Durable Polyester
- GLOSS
- Ultra Matt 0-10GU
- CURING
- 200°C for 10 minutes, based on actual metal temperature; products curing down to 160°C are available
- KEY FEATURE
- TGIC-free
- LEAD TIME
- 1-7 days
Product Overview
Description
PP1F is a polyester-HAA sand-textured powder coating for outdoor decorative and protective use. It is TGIC-free, meets applicable REACH restriction requirements, and is suitable for relevant markets including Europe. Performance can be aligned with QUALICOAT Class 1 and GB/T 5237.4-2017 (Class I), with curing down to 160°C available. Conventional sand-textured products may involve PFAS restrictions; PFAS-compliant options should be confirmed separately.
Key Features
- TGIC-free;
- good weathering and corrosion resistance;
- stable matt sand-textured appearance;
- good hiding power and coating yield.
Best Suited For
- Architectural aluminium profiles, doors and windows;
- Energy-storage cabinets, electrical cabinets, signal cabinets and automated logistics racking;
- Automotive components and metal furniture;
- Vacuum flasks, subject to prior confirmation of applicable requirements.
- Packaging
- 20kg or 25kg / box, in cardboard box lined with a polyethylene plastic bag
- Storage
- Store sealed below 25°C ,keep cool, dry, and away from sunlight.
- Shelf Life
- 6–12 months when stored under the specified conditions in unopened packaging, subject to the specific product.
- MOQ
- 100kg
Appearance & Properties
| Parameter | Value |
|---|---|
| Chemistry | Polyester-HAA |
| Color Values | LAB: 53.53, -2.2, -15.48 RGB: 108, 130, 154 |
| Gloss at 60° | Sand-textured finish ≤10 GU |
| Specific Gravity | 1.3–1.8 g/cm³, depending on colour and texture |
Application & Processing
| Parameter | Value |
|---|---|
| Curing Conditions | 200°C for 10 minutes, based on actual metal temperature; products curing down to 160°C are available |
| Application Guidelines | This series is suitable for manual or automatic electrostatic spray guns.Other application methods, including triboelectric spraying and electrostatic fluidized-bed coating, should be specified in advance. |
Performance Test Results
| Test | Result | Standard |
|---|---|---|
| Initial adhesion | Pass, Gt 0–1 | ISO 2409 |
| Impact resistance | 2.5 N·m; no coating detachment from the substrate under direct impact | ISO 6272 |
| Pencil hardness | ≥F, depending on the specific product | ASTM D3363 |
| Bend resistance | 5 mm; no visible coating detachment | ISO 1519 |
Certification & Compliance
| Compliance Item | Verification | Document |
|---|---|---|
| REACH | Supplier declaration | Request |
